Equipment weight |
3 tons |
|
The motor power |
Motor 5.5Kw pump station 5.5Kw working voltage 380V or customized |
|
Production speed |
10--18 m/min |
|
The transmission way |
1 inch chain drive |
|
rack |
Large frame: 350H section steel |
|
shaft |
14row axis diameter 70 mm solid shaft |
|
The thickness of the plate |
14 mm |
|
Set of |
Galvanized pipe finishing, electrostatic spraying |
|
Wheel material |
45# steel hard chrome plating |
|
The molding part |
Divided into precision wheel rotation forming, forming effect is good, reduce the friction between wheels and raw materials, debugging convenient, fast. |
|
Numerical control system |
PLC panel, kel-320 display |
|
counter |
Domestic photoelectric rotary encoder, a40s6-600-2-12-acp |
|
shear |
Iron plate welding frame, hydraulic cylinder automatic shear, hydraulic cylinder automatic pressure |
|
In the thickness of the plate |
0.3 mm - 1.0 mm |
|
Into the plate width |
1000 mm |
|
accessories |
Two sets of feeding rack, vulnerable parts |
|
Warranty period |
12 months |
The process for work: decoiler→feeding→roll forming→measuring length→cutting to length→product to stand
